A Kenmore washer that’s not operating effectively can create a myriad of issues, especially when it doesn’t have cold or hot water. It can be a hassle to wash clothes that have become dirty, and can cost a lot to hire a professional to fix the problem. A lot of issues related to hot or cold water in the Kenmore washer are easily fixed by the homeowner.
The following article will cover the most common reasons that your washer isn’t running hot or cold water, and offer step-by-step suggestions. We’ll help you fix the thermostat as well as check the water supply. If you’re struggling with a problem with your machine, or you just wish to save money for repairs, keep reading to find out how to fix a Kenmore washer with no hot or cold water.
Inlet Hoses and Screens
Kenmore washing machines are connected to your household water supply by fill hoses. They typically measure around 4-5 feet long and have an aluminum or wire screen at the top that connects to the faucet. This screen stops dirt from entering the water valve of the appliance. It’s located at the rear of the. How to check the condition of your Kenmore washing machines screen and hoses
- First, make sure the faucets and hoses are in good condition.
- Shut off the faucets. disconnect the fill hoses and the valve that is inlet, and then inspect the screens that are a part of the valve. Get rid of any dirt or sediment you discover.
- To confirm that you have enough water pressure to fill the hoses place the hose’s ends into the tub or bucket and begin to turn on the faucet. If you are experiencing low pressure then check the screens within the hose to check for dirt or damage. 4. If you discover any problems during these inspections, you’ll need Kenmore screen and hose replacement.
Water Inlet Vave
The Water Inlet valve that is on your Kenmore washing machine is able to supply cold and hot water to washing and rinse. It will come with two solenoids that operate inlets that control both hot and cold water supplies. The timer or electronic control and the selector for water temperature and the water level pressure switch are the controls for the valve.
The valve is controlled by the electronic control or timer as well as the water temperature/cycle selector switch as well as the pressure/water level switch. How to test the valve for water inlet inside aKenmore washing machine using a multi-meter:
- Before beginning the inspection, make sure that your washer is disconnected from the power source and water supply.
- To remove the valve to test, you’ll need to take out all or part of your Kenmore cabinet of your washer. You’ll see the valve in the middle of the hose connection.
- Inspecting for signs of damage, cracking or wear, look at the Kenmore washer’s valve. The valve is equipped with screens within it, which could have built up dirt or debris, if so, it should be thoroughly cleaned. If the screens get damaged, you will need to replace the entire valve.
- The resistance of a functioning valve can vary from model to model. Consult your manual to determine what your reading should be. To test for continuity, place the probes on the valve’s connections using your multi-meter set to Rx1. 5.If you do not receive a reading that indicates continuity, you’ll require a Kenmore replacement water inlet valve.
The lid switch in top load Kenmore washer machine is a safety mechanism created to prevent the motor circuit from operating while the lid is closed. Certain models also come with a valve for water inlet that can be controlled. There is a lid switch that controls the power supply. It is recommended to inspect the lid switch if the water inlet valve of your Kenmore washer has stopped receiving electricity. How to check the lid switch on the Kenmore washer:
- Before you start, make sure that your Kenmore washer is unplugged.
- In order to locate the switch, you’ll need to remove the cabinet’s top or top panel. Once you’ve located it, be sure the actuators as well as the levers aren’t damaged or stuck. Additionally, be sure the switch is operating mechanically.
- If there aren’t any issues above, remove the switch so that you can test it for continuity and set your multimeter to Rx1.
- Click the button to turn on the switch. After that utilize the probes to reach the terminals. The result should be of zero or near zero.
- If you receive a different reading, you’ll require a Kenmore lid switch replacement.
Selector Switch or Water Temperature Switch
The selector switch or the water temperature switch determines the water temperature for the rinse and wash parts of the cycle. The switch is able to provide power to the appropriate solenoids on the valve to supply water. If there is no electricity to the solenoids located on the water valve’s inlet, then the temperature selector switch could be at fault. What to do to test a Kenmore washing machine selector switch with a multimeter
- It is essential to unplug the Kenmore washer first before you are able to test it and unplug electrical components.
- To test your appliance, take off the switch that controls your selector. Also, you will need to dismantle each of the cabinetry in your washer. In most models, it is attached to the frame of the Kenmore washing machine.
- You will be testing the buttons on the switch one at a time. Start by placing probes on the buttons’ terminals Your reading should be infinity by this point. press in on the button, this should change your reading to zero and then press the other button, this will bring the reading back to infinity.
- If the readings you receive differ from those listed above, you’ll need a Kenmore replacement selector switch.
Water Pressure Switch
The water level switch, which is part of the water valve circuit and is a pressure-activated device. It is typically located behind the control panel and will contain a hose, or a dome tube that connects it to the tub. This switch can be found under the tub in Kenmore washers equipped with electronic controls. The switch might stop providing electricity to the valve to supply water in the event that it has been damaged. How to test the water level control switch in the Kenmore washing machine
- Before you start, unplug the power supply to the Kenmore appliance.
- A malfunctioning air dome or switch can cause similar symptoms as the defective switch. Determine if the hose is the cause by opening your washer’s cabinet and removing the air dome and hose. With one end closed blow it into another end, when the hose is submerged in water. No bubbles should appear on the surface.
- To look over the appliance to find indications of wear, cracks or damage or any other issue, remove the switch. It likely will be located on the bottom of the sump beneath the tub or in the area behind the control panel.
- If you spot any issues in your components while conducting the checks above, you may need Kenmore replacement water level switch.
The timer or electronic controller is used to control the time that the valve for water inlet receives the power. A number of electrical contacts are the basis of the mechanical timer. These contacts are controlled by tiny motors and cams. These contacts will provide electricity to the water inlet valve circuit throughout the rinse, fill and rinse sections of the cycle. How do you check the timer control of aKenmore washer machine using a multimeter
- To locate the timer, unplug your Kenmore washer and remove its control panel and its rear panel.
- The timer must be taken off of your Kenmore washer Do not pull directly onto the wires, rather pull the metal connectors connected to the wires.
- Set the multi-meter’s setting to Rx1 and while you are pressing in on the button (if it is applicable), place the probes on the terminals which are connected to the motor (refer to your wiring diagram). You’re testing for continuity, and you should get either almost zero.
- You’ll need a new Kenmore timer when your test results are different. A Kenmore washer with no hot or cold water is an issue that is frustrating and may be challenging to fix, but it’s typically quite easy.
You can troubleshoot common problems such as clogged pipes, faulty valves and incorrect temperature settings for your water by following the guidelines in this article. Before you make any repairs to your Kenmore washer, disconnect it. If there are any issues you should consult the manual or contact a professional. It is possible to repair your Kenmore washer back in working order quickly and efficiently with a little patience and time. This will spare you from the hassle of washing clothes and the cost of repairs.
