How To Fix Hotpoint Washing Machine Timer Wont Advance

How To Fix Hotpoint Washing Machine Timer Wont Advance

If you’re Hotpoint washing machine’s timer isn’t able to advance, it can be a frustrating and time-consuming problem to resolve. There are a variety of steps you can try to solve the issue. In this article, we will explore some common causes of a Hotpoint washing machine timer that won’t advance, and provide step-by step instructions for fixing the problem. Whether you’re a seasoned DIYer or new to DIY home repairs, this article will assist you in getting your Hotpoint washing machine up and running again in no time.

Lid switch

The lid switch is a safety option on top loading Hotpoint washing machines. The lid switch is usually located beneath the main top. It has a projection over or connected to the lid. It will turn on the switch when it is shut. The motor circuits as well as the timer are powered by the lid switch. How to check the lid switch on aHotpoint washing machine using a multimeter:

  1. Unplug your Hotpoint washing machine.
  2. Take the cabinet off or the top panel, and then locate the lid switch.
  3. After finding the switch, first begin verifying that the levers or actuators have been damaged or stuck and the switch is active mechanically when the lid is closed.
  4. If no issues are found during the above tests then remove the switch and set your multi-meter to the Rx1 setting. Press and hold the switch’s button, position the probes on the switch’s terminals, you should see a reading that is zero.
  5. If you see another reading, you’ll need a new lid switch.

Timer & Timer Motor

The timer is used to regulate all functions of the Hotpoint washer. A number of electrical contacts can be seen within the timer. These contacts are controlled by a cam that is moved by a motor. The contacts inside the timer function to control the timer motor. If the timer in your washer does not move it is possible that the timer or motor might be malfunctioning. Test the timer and timer motors in aHotpoint washing machine using a multi-meter:

  1. Unplug the Hotpoint washing machines from the source of power.
  2. Locate and then remove the timer from your appliance. To access the control panel and rear panel, you will need to remove them.
  3. Set your multi-meter to Rx1 and then connect the probes to the terminals which are connected to the motor (refer to the wiring diagram). You are testing for continuity, and you should get an error of zero or close to zero.
  4. If you find that your test gives different results, you will require an new timer.

Water Level Control

The water level control in Hotpoint washing machines allows for turning the water valve off and on at the levels you choose, as well as to supply power to the motor when the right water level is reached. If your washer fills but the timer is unable to advance , it could be due to an issue with the water level switch. How to examine the water level control in the Hotpoint washing machine:

  1. Before you begin, disconnect the washing machine since you’ll be handling electrical components.
  2. Before you can determine if there is a problem with the switch If you suspect that the switch is not functioning, take off the air dome tube. To locate and take out the air dome hoses, take out the cabinet. Place the hose in water and seal the ends. After that, blow air through each end to check for bubbles. You must also examine the pipe for signs of wear, cracks or other obstructions.
  3. If you have not found any issues, you might need the replacement water-level switch.

Timer Knob and Dial & Skirt

The timer knob or dial is attached to the timer shaft and will rotate as the timer moves through a time. It is also possible to pull out the knob and activate the timer’s switch. The timer knob is normally constructed of plastic and is reinforced by a keyed insert of metal which is connected to the timer shaft. In normal use, it can result in the knob to crack or wear out, making it impossible to be able to turn in the direction of the shaft. This can make it more difficult to adjust the timer to the desired cycle. The cause is that the dial to not move along with the shaft as the cycle progresses. How to check the timer knob of a Hotpoint washer:

  1. Remove the Hotpoint washer from the power source.
  2. To locate the timer knob you’ll have to remove the cabinet or the rear panel to reach the back.
  3. Check the knob to make sure that the timer has been activated as the knob is pulled away and pushed in.
  4. If it doesn’t engage then you’ll require new knobs.

Drain Pump

The drain pump drains the water from the Hotpoint washing machine at the end of the rinse and wash sections of the cycle. If the drain pump is not working, then the washer from Hotpoint will not sense that the tub has been empty and will not move on to the next portion of the cycle. If your washer is unable to continue after the rinse or wash portion of the cycle, you should examine the drain pump is operating correctly. Some models with electronic control could display a fault message when this problem occurs. If your Hotpoint machine is flashing an error code then you should refer to our list of commonly used appliance fault codes to identify the root cause. How do you examine the drain pump in the drain of a Hotpoint washing machine?

  1. Unplug the Hotpoint washer.
  2. Locate your drain pump. To get to the pump, you’ll need to remove it off the front of the appliance.
  3. Once you have found the pump, check all the connections and hoses that come off the pump for leaks or damage.
  4. If the leak is coming through the pump, you’ll require the new pump.

Water Inlet Valve

The water inlet valve supplies cold and hot water to Hotpoint washers during fill parts. The valve will have at least two solenoids to open the valve when it is needed. The valve that opens the water supply could be the reason for the issue if your washer stops moving through the cycle and stalls during the rinse fill or wash part. Check first that the inlet hoses aren’t have any kinks or restrictions and that the screens for inlet are free of dirt. The screens should be clear. The next step is to examine the resiliency of the solenoids using the multimeter. How to check the water intake valve within theHotpoint washing machine using the help of a multimeter:

  1. Before you begin the Hotpoint washer, ensure that the washer is not plugged in.
  2. Find the water inlet valve and take it out. It’s likely to be in the middle of the hose connections; you will need to remove all or part of the cabinet to access it.
  3. The screens inside the valve for signs of buildup or debris be sure to do this in a safe manner since the screens are not able to be replaced and if they are damaged you will need the replacement of the valve.
  4. If you notice damage or wear on your pump, switch on your multimeter, and connect the probes to the appropriate terminals. Check the manual for more information on what this test should show, since it varies between models. next.
  5. You will need a replacement valve for your water if your readings are out of the normal range.
