A leaking Roper washing machine could be an expensive and frustrating issue to tackle However, it’s often an issue that can be solved with just a few hours of experience and a few tools.

This article will outline the most frequent reasons for the washing machine of Roper to leak and will provide step-by step instructions for fixing the issue. It doesn’t matter if it’s an insignificant leak or a massive flooding, we’ve got you covered. You can quickly repair a leaky washing machine and get it back to normal with your laundry.


If you notice that your washer is leaking , you must first examine the hoses. There are a variety of hoses located on a Roper washer, but drain and fill are the most well-known. How to inspect the hoses that are on your Roper washing machine:

  1. To make sure they’re properly tightened, look at the connections on the back. In the next step, check to see if there isn’t any obstruction in the drain.
  2. If no leaks are detected when you examine the hoses on the outside, disconnect your washer from the source of power and remove the cabinet from the Roper washing machine to examine the internal hoses.
  3. There are a variety of internal hoses, and the majority are found attached to the tub. Inspect the hoses for cracks, abrasions , or other damage.
  4. You’ll have to replace the damaged hoses with a Roper replacement.



Pump Water Pump:

The water pump, also known as a drain pump is the piece on a Roper washing machine which drains the water out of the tub. You can choose to have the pump belt driven or direct driven. It is also possible to require an electric pump.

  1. Before you start the process, you must disconnect your Roper washing machine from the power supply.
  2. Take out the front or cabinet of your appliance. Find your pump(s).
  3. A drain outlet or hose , will be supplied by the pump. It may also have an inlet from your tub. There may also be an outlet that circulates. If you have water leaking out of the Roper washer in the course of a wash or drain cycle, you should check the area of the drain pump.


Check for indications of a loose or loose hose clamp or leaky water hose that is connected to the pump in first. If the leak is coming from the pump, you’ll need an upgrade to the Roper pump.


Tub Cover Gasket

Tub Cover Gasket on front and top load Roper washers is used to provide a seal between the tub’s exterior and the tub cover. Tub cover gaskets may be responsible for leakage of water during wash or spin. How to check the gasket in the tub of a Roper washing-machine:

  1. Unplug the Roper washer, then remove the front panel or cabinet.
  2. Locate the gasket on the tub cover. You may need to take off the tub cover to gain access to it.
  3. The gasket should be inspected to check for wear and damage. Additionally, check out for water stains or flowing from the area to determine the cause.
  4. If the gasket in your tub is worn, damaged, or there are signs of leakage in the area You will require a Roper replacement gasket for the tub cover.


Water Inlet Valve

The valve for water inlet on the inside of your Roper washing machine controls the introduction of hot and cold water into your washer. How do you inspect your Roper washing machine’s water inlet valve:

  1. Before you begin, shut off the water and power source from the machine.
  2. Remove the back panel of your machine and locate the valve that opens the water supply. It likely will be located just behind the hose connections.
  3. Remove the valve from the washer and examine the screens for any debris or buildups. It is important to be cautious since the screens can’t be changed. If they’re damaged, you will have to replace the entire valve. Also, examine the valve for wear, cracks or damage.
  4. Using the multi-meter in Rx1 mode, connect probes on the terminals of the valve. The result you’ll get varies from model to model Check your owner’s manual to determine what the recommended reading for a functioning valve is. If you receive unsatisfactory readings within the acceptable range, or if the valve is damaged, you’ll need an Roper replacement valve.


Bellows or Door Boot Seal:

This seal seals between the tub and the door on front-load Roper washers. Wear and tear from normal use can cause the bellows’ rubber to crack. Additionally, foreign objects could cause damage or tear to the bellows, causing a leak at the front of the Roper washer. If your washer is leaking or appears to be leaking near the door, you must suspect that the bellows might be the reason. How to inspect the bellows on a washing machine:

  1. Disconnect your Roper washer from the power source.
  2. The door should be opened and examine the bellows to look for signs of damage or for accumulation of dirt and soap which could cause a weak seal to the door. Be aware that foreign objects can cause severe injuries and are usually hidden within the bellows ‘ folds.
  3. Roper replacement bellows is needed if you suffer from any of these symptoms.


Water Level Switch, Pressure Switch & Air Dome Tub

The leaky Roper washer can result from overfilling. The water level switch which is activated through pressure is used to adjust the level of the water within the tub. As the water fills the tub, it compresses the air in the tube, pushing against an inner diaphragm within the switch. The water inlet valve will be controlled by the switch, which will shut off the valve when it reaches the appropriate water level. How to inspect the switch for water level on your Roper washing machine:

  1. Since you will work on electrical components, you must make sure that you’ve shut off the power source for your washer.
  2. Locate and take out your water level switch. The switch for water level is normally situated behind the control panel. It will be connected to the tub with a hose, or air dome tube. This switch can be found below the tub in Roper washers equipped with electronic controls.
  3. To identify whether the switch is defective, you should first eliminate the air dome hose as the cause of the problem. Check for worn and cracked areas on the hose. Immerse the hose in water and then remove it. Close one end, and blow air into the other and check for bubbles. You should check for obstructions in the hose too. If the hose with an air dome appears to be in good condition, you may need a replacement water level switch from Roper.


Door Catch

The door catch on the front load Roper washing machine is responsible to ensure that the door is closed tightly during the cycle. The mechanism for locking the door is designed to secure the hook or door catch in order to prevent it from opening in the cycle. If the door catch is damaged, it could allow the door to be locked, but will not guarantee an watertight seal. How do you check the door catch of a Roper washing machine’s door catch:

  1. Based on the model you have you may have to remove the front panel in order to get access to the door catch in sufficient detail for you to check it. In some models, you’ll be able to access it by simply by removing the screws that hold it in the position. If you are required to remove the front panel in order to get it out, unplug the appliance prior to beginning.
  2. Check the door catch to see whether it’s cracked, discolored, worn, damaged, or if there are any foreign objects which could be preventing the door from shutting properly.
  3. It is necessary to replace the Roper door catch if you notice any damage or wear.


Tub Seal Or Boot Seal

Tub Seal or Boot Seal a Roper washing machine is designed to stop water from spilling out where the transmission shaft or basket shaft is inserted into the tub. The problem with defective seals usually starts as a tiny water leak but they can cause an issue with the main tub bearing. The tub seal might be damaged and require to be replaced if your washing machine is leaking during filling or agitation. You can examine the tub seal on the Roper washing machine by following these steps:

1. Take off the front panel from your washing machine and allow it to fill up with water as usual. For signs of damage to the tub, look for the area where the transmission shaft goes into the tub.

2. Rear access panels must be removed from front load washers. Look for signs of water loss from the weep holes in the housing for bearings on the rear. If you notice any water leaking out of the weep holes situated near the housing housing for the rear bearing, you’ll need to replace the tub seal from Roper.
