A strong smell emanating from your Miele washing machine could be an alarm signal and could signal an urgent issue that has to be dealt with immediately. There are numerous reasons why this could happen, including worn bearings, malfunctioning belts or motor problems. In this post, we’ll look at the main causes of an unpleasant smell emanating from the Miele washing machine and provide steps on how to fix and diagnose the problem. We’ve got you covered no matter if you are facing a minor issue or a major glitch. It’s easy to repair the problem with a Miele washer with a burning odor and get back to normal laundry without hassle if you take the right approach.

Drive Belt Or Spin Belt

Some models of top loading Miele washers utilize a belt to drive the transmission. The belt could be the issue if the Miele washer ceases to agitate. What to do to determine if the drive belt in the Miele washing machine is in need of replacement:

  1. Disconnect your Miele from power sources prior to it starts.
  2. You will need to take off the clamps holding the drive belt in place. The drive belt will be connected to the motor that drives it. You will need to remove the rear panel or cabinet in order to get it.
  3. Once you’ve removed the belt, inspect the belt for indications of fraying, cracking, burning, or any other damage.
  4. You can replace your belt using a Miele replacement belt in the event of problems.

Pump Belt

Some top load Miele washers have an engineered belt to drive the drain pump. The belt is a standard V-shaped belt that is attached to the pulley of the drain pump. A pulley with an idler can be used to tighten the belt. If you smell a burning smell of rubber from your Miele washer, check the pump belt. How can you tell if the pump belt in theMiele washing machine needs replacement:

  1. Disconnect your Miele washer from its power source and open the cabinet for your washer.
  2. To examine the belt, locate it and take it off. The belt of the pump is tied to the pulley of the drive motor. To remove it you’ll need to take off the clamps holding it in the place.
  3. Examine your pump visually for indications of wear, burn fraying, or damage.
  4. You’ll need to replace your Miele pump belt when your belt exhibits any of these indicators.

Motor Pulley The drive motor is equipped with a pulley for turning the belts of the pump or drive. The motor pulley is designed to make the most contact with the belts and may be made of metal or a synthetic material. The pulley is susceptible to wear or rusted and result in excessive friction, excessive heat, or even damage to the belt. It could cause a burning odor. How to examine theMiele washing machine motor pulley:

  1. Before you start this examination, unplug your Miele washer.
  2. Find and take off the motor pulley to inspect it thoroughly. To do this, you will have to remove the cabinet and take out any belts attached to it.
  3. You must examine the motor pulley for dirt, grease and other debris. Also, look for signs of wearor burns, or damage. If the pulley is damaged or wear, you’ll be required to replace it using a Miele replacement.

Drain Pump

The drain pump is utilized in Miele washing machines to drain water from the tub before and following the spin cycle. It is motor driven belt driven, electric or motor driven. The drain pump may be shut down if there is an unpleasant burning smell emanating of the Miele washer following or during the spin cycle. The burning smell is typically due to the belt sliding across the pulley of the pump in belt-driven models. Models with an electrical drain pump may smell like an electric motor. What is the procedure to inspect the drain pump on a Miele washer?

  1. Disconnect the appliance’s power supply and then take out the cabinet or the front panel.
  2. Once you have located the pump, begin with examining all the connections and hoses running off the pump to determine if the pump is the source for the leak. Replace the connector or the hose if there are any issues.
  3. If the leak is from the pump, you’ll have to replace it with a Miele replacement Pump.

Idler Pulley Wheel & Idler Pulley Arm

Some models of top load Miele washers have an idler pulley mechanism to ensure tension on the pump belt or drive belt. If the idler pulley becomes blocked or the idler arm doesn’t pivot in a fluid manner, the proper tension for the belt will not be established and belt slippage or friction will take place, which can cause the belt to overheat and produce an unpleasant smell. How to check the condition of aMiele washing machine’s idler arm and wheel:

  1. Verify that you have removed your Miele washer from its electrical source prior to beginning the process, and then open the cabinet to inspect the washer.
  2. Examine your idler pulley wheel, and arm. You are looking for any indications of wear, damage, cracking, or burning. The drive belt will be tied to the pulley. you’ll need to remove it in order to check the pulley. To get rid of the belt, tilt the idler pulley toward the drum in order to reduce the tension on the belt enough to allow it to slide off.
  3. To make sure that the operation is smooth, inspect the pulley wheel. It should not move or resist.
  4. You’ll need to replace the idler pulley arm or wheel If you experience issues with the above checks.

Direct Drive Motor Complement

Top load Miele washers employ direct drive motor couplings instead of belts to transfer power from the motor to transmission. The drive coupling constructed comprising two plastic drive forks, as well as an elastic coupling. It joins the motor to the transmission. One drive fork is connected to the shaft for the drive motor, while the other one is connected to the transmission’s input shaft. The rubber coupling that connects the drive forks absorbing torque and preventing them from breaking when the motor shaft turns. The normal use of the coupling will cause wear on the coupling, and then the drive forks can be slipping and produce an unpleasant burning smell. How to inspect a Miele washing-machine’s direct drive motor coupling:

  1. Similar to other inspections you should ensure that the Miele has been disconnected from the electricity source.
  2. It is necessary to remove the coupling from the Miele washer to observe it with a keen eye. It is necessary to remove the entire cabinet that houses the washer. In accordance with the model you will also have to take out the motor or drain pump.
  3. Check the coupling between the motor and the engine to determine if it is showing signs of wear, cracking, burning or damaged.
  4. If you encounter any problems with your motor coupling you’ll need a Miele replacement direct drive motor coupling.

Clutch Assembly

Some top-loading Miele washers come with a clutch assembly that drives the washing basket during the spin cycle. If your Miele washer emits a strong burning smell, it could be the result of the worn-out clutch. Your washer may be able to make a loud scraping sound during the spin process. Another sign of a worn-out clutch is brake dust or shavings located beneath the Miele washing machine. How to inspect the clutch in a Miele washing machine:

  1. After the appliance has been disconnected from power sources, you can open the cabinet of the Miele washer to see the clutch unit.
  2. To examine the clutch assembly, take it off the Miele appliance. It will usually be found under the tub’s exterior connected to the drive assembly for the basket. You might need to take the drive motor and transmission off based on the model.
  3. Examine your clutch assembly for signs of burns, wear, fraying or other issues.
  4. If you spot any of the symptoms above then you’ll need an Miele replacement clutch assembly.

Glide and Spring

Some models of Miele washing machines have a spring and glide arrangement on the drive motor to aid in belt tensioning. The drive motor will usually have a pivot mount fixed to the base frame and springs that provide tension. A lubricated plastic or nylon glide is fitted to the bottom of the motor to allow it to slide on the Miele washer base frame. This will allow the drive belt and pump belt to slide a bit when the motor is turned on. It acts as a clutch. If the belt does not glide freely, the belts can become overheated and produce a smell that is burning. How to check the spring and glide on Miele washing machine.

  1. Before starting, unplug your Miele washer.
  2. Remove or take off the front panel of the washer to discover the spring(s) or glide(s). The springs and glides for the drive motor by taking off the front panel.
  3. Verify that the motor pivots correctly ensure that the springs aren’t stretched, and make sure the surface is clear of any dirt or rust.
  4. Examine the glide(s) for signs of wear, burning or damage. Lubricate them when needed.
  5. Miele replacement springs could be needed if you discover any problems or damaged parts when conducting these checks.

Drive Motor

In most Miele washers the main drive motor is utilized to control the mechanical components of wash cycles , such as the agitation process, as well as tumble and spin. It could also be used for the operation of the drain pump. A fault in one of the motor’s components can cause it to overheat and produce a burning odor. If the problem is severe, it may also overheat the motor to cause the motor to break down. A failing drive motor might be characterized by the sound of a ringing or loud noise at the time it starts. Here’s how you check the drive motor of the Miele washer:

  1. After you’ve confirmed that you’ve removed your washer from the outlet, you can remove the cabinet of your Miele appliance.
  2. Take the drive motor off to test it. There will be many wires connected to it. Take them out by pulling on the metal connectors and not the wires.
  3. You should test your ground connection as well as the continuity of the motor. For both of these tests, the multimeter must be set at Rx1. To check continuity, you can touch the probes to the motor terminals. This should produce a reading that is near or zero.
  4. To determine the ground connection, put one probe on the terminal and connect another probe to the housing of the metal, you should not have any readings in this test.
  5. If the readings from your multimeter do not match the above, then you’ll require a replacement Miele drive motor.
