A leaky LG washing machine is an extremely costly and aggravating issue to resolve however it’s an issue that is fixed easily with a bit of knowledge and a few tools. In this article, we will look at the main causes of a leaky washing machine from LG and provide step-by step instructions on how to resolve the issue. We’ve got you covered, no matter if you are dealing with a minor water leak or major flooding. With the right approach you can fix a leaking washer and get back to your laundry in the shortest amount of time.
Hoses
If your washing machine is leaky, it is best to look at the hoses. There are numerous types of hoses located on the LG washer, however the drain and fill are the most well-known. Here’s how to test the hoses on your LG washer:
- To ensure they’re tightened, inspect connections at the back. In the next step, check to see if there’s no obstruction to the drain.
- If no signs of leaks can be found when you inspect the external hoses, disconnect your washer from the source of power and remove the cabinet from your LG washing machine to inspect the internal hoses.
- Many internal hoses connect to tubs. Check the hoses for signs of cracks, abrasions, or other damage.
- If you find a damaged hose(s) that is damaged, you’ll require LG replacement hose(s).
Pump
The water pump or drain pump is the piece on a LG washing machine that removes water from the tub. The pump could be belt driven directly drive, direct drive or an electric pump.
- Before you begin making connections, unplug your LG washing machine from the power supply.
- Remove the front or cabinet of your appliance. Locate your pump(s).
- A drain outlet or hose will be provided by the pump. It may also have an outlet from your tub. It could also have an outlet with a circulation. If water is leaking from the LG washer during a drain or wash cycle, you should check the area of the drain pump.
- Check for loose clamps on the hose or leaky hoses attached to the pump. If the leak is coming from the pump, then you’ll need an upgrade to the LG pump.
Tub Cover Gasket
The tub cover gasket for front and top load LG washers is utilized to form a seal between the tub’s outer and tub cover. Tub cover gaskets could be responsible for water leakage during wash and spin. How to examine the gasket in the tub of a LG washing-machine:
- Unplug the LG washing machine and pull off the cabinet or front panel.
- Locate the gasket for the tub cover. It is likely that you will have remove the tub cover to gain access to it.
- You should inspect the gasket for wear and damage. Additionally, check for water spots or leaks from this location to determine the cause.
- If your gasket is worn, damaged, or you notice signs of leaks in the vicinity it is time to get a LG replacement gasket for the tub cover.
Water Inlet Valve
The valve for water inlet on the inside of your LG washing machine controls the entry of cold and hot water to your washing machine. How do you examine the water intake valve on your LG washing machine:
- Unplug the power source as well as the water source from your washer prior to starting.
- Remove the panel on the back of your machine and locate the water inlet valve. It is likely to be behind the hose connections.
- After removing the valve from the washer, examine the valve’s screens for any debris or buildups, removing anything you find. It is important to be cautious since the screens cannot be replaced. If they are damaged, you will have to replace the entire valve. Also, inspect the valve for signs of wear, cracks or damage.
- Using a multimeter, in Rx1 mode, put probes on the valve’s terminals. The valve should give a different reading depending on the model. Consult your manual to determine what the reading should be for a functional valve. If you receive unsatisfactory readings within the range recommended or if the valve is damaged, you’ll require a LG replacement valve.
Bellows Or Door Boot Seals
The door bellows or door boot seal is installed for front load washers by LG to secure the door and the outer tub. The rubber bellows can crack due to wear and wear and tear. Additionally, foreign objects can cause leaks to the front of your LG washer. If your washer is leaking or appears to be leaking near the door area, then it is possible that the bellows are the reason. How to inspect the bellows of a washing machine:
- Disconnect your LG washer from the power source.
- Make sure the door is free of damage, dirt, or buildup. Be careful as sharp foreign objects that can cause tears are usually found in the folds the bellows and may present risk.
- If you experience any of the symptoms above then you’ll need LG replacement bellows.
Water Level Switch, Pressure Switch & Air Dome Tub
A leaky LG washer can be the result of overfilling. The water level switch is a switch that activates pressure which is used to determine the proper level of water in the tub. As the water fills the tub it will compress the air inside the tube and push against a diaphragm inside the switch. The valve for water inlet will be operated by the switch, that shuts off the valve when it reaches the appropriate water level. How to inspect the switch for water level in your LG washing machine:
- Before you begin, make sure that you have removed the electricity from the washer because you’ll be dealing with electrical components.
- Locate and take out the water level switch. The water level switch is usually hidden behind the control panel. It will be connected to the tub by the use of a hose or air dome tube. In LG washers that use an electronic control, the switch could be located at the bottom of the sump beneath the tub. To check if the switch has problems, first unhook the air dome hose.
- Examine for indications of worn or cracked areas on the hose. Then, remove the hose and submerge it in water. Make sure the end is sealed by blowing air into one end, and look for bubbles. Also, look for obstructions within the hose.
- If the air dome hose seems to be working, then it is possible that you need an LG replacement water level switch.
Door Catch
The front-load LG washer’s door catch responsible for locking the door in the washing cycle. The mechanism that locks the door is designed to engage the hook or door catch and stop the door from being opened during the cycle. The door catch can be wornout, but it will still lock the door. How to inspect a LG washing machine’s door catch:
- Depending on your model it may be necessary to take off the front panel in order to get access to the door catch sufficiently to look it over. In other models, you’ll be able to access it by simply taking off the screws that hold it in place. If you must take off the front panel in order to gain access, disconnect the appliance prior.
- Visually inspect the door catch to see if it is cracked, worn or discolored or if there are any foreign objects that could prevent the door from fully closing.
- You’ll require a replacement LG door catch if you notice any wear or damage.
Tub Seal Or Boot Seal
The tub seal on a LG washing machine is used to keep water from leaks where the transmission shaft or basket shaft enters the tub. Seals that are defective often begin as a minor water leak but can eventually cause a failure of the main tub bearing. The tub seal could be damaged and require to be replaced if your washing machine leaks when filling or during motion. You can check the tub seal of a LG washing machine by following these steps.
- Take off the front panel from your washer and allow it to fill with water as normal.
- Check the area where the shaft for transmission is entering the tub for signs of a water leak.
- For front load washers, removal of the rear access panel is necessary. Check for evidence of water loss from the weep holes situated near the rear bearing housing.
- If you notice any signs of leaks while conducting the above checks, you will need a LG replacement tub seal.
