How To Fix Hotpoint Washer That Fills and Drains At The Same Time

How To Fix Hotpoint Washer That Fills and Drains At The Same Time

If you’ve been wondering the reason why your Hotpoint washing machine is filling up and draining at the same time, you’re not alone. This is a very common issue and can be caused by many things. In this article, we’ll go over the most frequent reasons behind this issue. We’ll provide step-bystep instructions for fixing an appliance from Hotpoint that fills and drains simultaneously. This guide is for you, whether you are a professional DIYer or an amateur. It will show you how to get your Hotpoint washer back to normal condition, no matter at what level you’re at.

Water Inlet Valve

The water inlet valve that is on your Hotpoint washing machine is used to fill the tub with cold, warm or hot water to wash and rinse cycles. The solenoids of the electric motor control the valve. They are controlled by the electronic control board along with the timer and water level control/water selector switch , or the pressure switch. If your Hotpoint washer continues to fill when draining the water inlet valve may be at fault. If the issue persists remove the plug from your washer. The valve at the inlet may be damaged if the washer is filling constantly. If the Hotpoint washer stops filling it is in the electrical circuit that regulates the valve. How to test the valve for water inlet on aHotpoint washing machine with a multi-meter:

  1. Before starting, disconnect the power and water source from the Hotpoint washer.
  2. The valve needs to be removed to test it; it is located behind the connections to the hose. You will need to disassemble every part or the cabinet for the washer in order to take it off.
  3. There are screens inside the valve that are filled with dirt and debris. Clean up any dirt or debris that you find. Screens cannot be sold separately and will have to be replaced when damaged. It is also important to inspect the valve’s exterior for damage, wear or cracks.
  4. Your owner’s manual will give you readings on resistance for functional valves. They vary between Hotpoint washer models. When you’ve achieved the desired reading, turn your multimeter to Rx1 and connect the terminals of the valve’s terminals. If your valve does not have continuity, you may use an Hotpoint replacement valve.

Water level switch, also known as a pressure switch and air dome tube

The water level switch, which is activated by water pressure, is used to set the water level within the tub. The part is usually situated in the back of the control panel, and it will be fitted with a hose or an air dome tube connecting it to the tub. On Hotpoint washers that have electronic controls the switch could be located in the sump area under the tub. The water will fill the tub and pressurize the air inside, pressing against the diaphragm. The switch will control the water inlet valve and shut off the valve at the correct water level. How do you check the water level in the Hotpoint washing machine

  1. Before working with electrical components, be sure to unplug your appliance.
  2. Start by opening the Hotpoint cabinet to the washer. Then, remove the air dome hose. In the water, place the hose and then seal the end. Then blow the opposite end into the water. You’ll need to replace the air dome hose when bubbles start to appear.
  3. Examine the switch and Hose for signs of fraying, cracking, wear, or damage.
  4. It is possible to replace your water level switch when it’s damaged.

A Hotpoint washer that drains concurrently is a source of frustration. However, with correct tools and the right knowledge the issue can be easily fixable. By troubleshooting the most common reasons for this issue that cause this issue, like a blocked drain hose or a damaged water inlet valve, or an inoperable pressure switch, you’ll repair your Hotpoint washer back in working order in no time. Make sure you look up your Hotpoint washer’s user’s manual for specific directions and unplug the appliance prior to making any repairs. With a little perseverance and knowledge you’ll be able to get your Hotpoint washing machine functioning as good as new in no time.
